Hanna HI22111-2 Wall Mounted ORP Digital Controller with Single Setpoint and Matching Pin

  • Manufacturer:HANNA
    Model: HI22111-2
  • 1,458,609 Kyat
  •  Call for best price

     Hanoi city: (024) 35.381.269

     Danang city: (0236) 374.77.11

     HCM city: (028) 38.119.636

ORP
ORP Range: ±2000 mV
ORP Resolution: 1 mV
ORP Accuracy: ±2 mV
Meter Temperature
Temperature Range: -9.9 to 120.0 °C
Temperature Resolution: 0.1 °C
Temperature Accuracy: ±0.5 °C
Process Control Meter
Alarm Relay Set Point: electromechanical relay SPDT contact output, 5A - 250 VAC, 5A - 30 VDC (resistive load) fuse protected: 5A, 250V, 250V fast fuse
Consent Relay: electromechanical relay SPDT contact outputs, 5A-250 VAC, 5A - 30 VDC (resistive load) (HI211YZ and HI212YZ), fuse protected: 5A, 250V fast fuse
Analog Ouput Signal: 0 to 1 mA, 0 to 20 mA, 4 to 20 mA; 0 to 5 VDC, 1 to 5 VDC, 0 to 10 VDC
Digital Output Signal: RS485
Power Consumption: 15 VA
Over Current Protection: 400 mA, 250V, fast fuse
Environment: 0 to 50°C (32 to 122°F); RH max. 85% non-condensing
IP Rating: IP54
Dimensions: 221 x 181 x 86 mm (8.7 x 7.1 x 3.4’’)
Weight: 1.4 kg (3.1 lb.)
Ordering Information : Supplied with instructions.
